Accuracy class

 0.03

Maximal capacity (Emax)

Weight (G), approx.

Sensitivity (Cn)
Zero balance
Temperature effect on sensitivity (TKc)
Temperature effect on zero balance (TKo)
Non-linearity (dlin)
Repeatability (drep)
Hysteresis error (dhy)
Creep (dDR)in 30 min.
Input resistance (RLC) [Red(+)-black(-)]
Output resistance (RO) [green(+)-white(-)]
Reference excitation voltage (Uref)
Maximal excitation voltage
Insulation resistance (Ris)
Nominal temperature range
Service temperature range
Storage temperature range

mV/V
mV/V
% of Cn/k
% of Cn/k
%
%
%
%
O
O
V(DC/AC)
V(DC/AC)
GO
^oC [ o F]
^oC [ o F]
^oC [ o F]

2±0.25%
±0.04
< ±0.0017
<±0.0040
<±0.023
<±0.017
< ±0.023
< ±0.023
770 ±30
700±5
0.5.24
36
>2[50 VDC ]
-10.+40[15.+105]
-30.+70[-20.+160]
-50.+85[-60.+185]

Safe load limit (EL)
Breaking load (Ed)

% of Cn
% of Cn

 150
 300

Protection class (IP) acc. to IEC529

Material
