Type		535TS
Accuracy class		0.5
Capacity	kg	2,000;5,000; 10,000 ;20,000;40,000;  70,000;100,000
Sensitivity (Cn) Zero balance Temperature effect on sensitivity (TKc) * Temperature effect on zero balance (TKo) Non-linearity (dlin) * Repeatability (drep) * Hysteresis error (dhy) * Creep (dDR)in 30 min. Input resistance (RLC) [Red(+)-black(-)] Output resistance (RO) [Green(+)-white(-)] Reference excitation voltage (Uref) Maximal excitation voltage nsulation resistance (Ris) Nominal temperature range Service temperature range Storage temperature range	mV/V mV/V % of Cn/k % of Cn/k % % % % O O V(DC/AC) V(DC/AC) GO oC [ o F] oC [ o F] oC [ o F]	1±10% ±0.05 < ±0.020 < ±0.020 < ±0.5 < ±0.3 < ±0.5 < ±0.2 400 ±25 350±3 0.5.12 15 >2[50 VDC ] -10.+40[15.+105] -30.+70[-20.+160] -50.+85[-60.+185]
Safe load limit (EL) Breaking load (Ed)	% of Cn % of Cn	200  400
Lateral load limit (Elq)	% of Cn	50
Permissible dynamic load(Fsrel)	% of Cn	100
Protection class (IP) acc. to IEC529		IP67
Material		Stainless steel
Optionally		Explosion proof version(Ex ib II CT4)
