Type		101BS
Accuracy class according to OIML R60 or NTEP Maximal numbers of load cell verification intervals ( n L C )		C3 / NTEP III 5 000 Multiple Cell 3 000 / 5 000
Maximal capacity (Emax)  Minimum load cell verification interval (Vmin) Sensitivity (Cn) Zero balance Temperature effect on sensitivity (TKc) * Temperature effect on zero balance (TKo) Non-linearity (dlin) * Repeatability (drep) * Hysteresis error (dhy) * Creep (dDR)in 30 min. Input resistance (RLC) Red(+)-black(-) Output resistance (Ro) Green(+)-white(-) Reference excitation voltage (Uref) Maximal excitation voltage Insulation resistance (Ris) Nominal temperature range Service temperature range Storage temperature range	lb/kg % of Cn mV/V mV/V % of Cn/k % of Cn/k % % % % O O V(DC/AC) V(DC/AC) GO oC [ o F] oC oC	500;1,000;1,500;2,000;2,500;3,000;5,000;10,000; 15,000;20,000/300;500;1,000;2,000;5,000;10,000 0.02 2.0 +25%/ - 10% ±0.06 < ±0.0012 <±0.0040 <±0.023 <±0.030 <±0.030 < ±0.030 400 ±20 352±3 0.5.10 15 >2[50 VDC ] -10.+40[15.+105] -18.+65[0.+150] -50.+85[-60.+185]
Safe load limit (EL) Breaking load (Ed)	% of Cn % of Cn	150 300
Protection class (IP) acc. to IEC529		IP68
Material		Stainless steel 17-4PH
Optionally		Explosion proof version (Ex ib II CT4)

* The data for deviation of linearity, repeatability, hysteresis error and temperature effect on sensitivity are typical values. The sum of these data meets the requirements according to OIML R60 or NTEP 1:5000 class III Multiple Cell.
