Type		563YH
Accuracy class according to OIML R60 Maximal numbers of load cell verification intervals  ( n L C )		- 3000	C3 3000 / 5000
Maximal capacity (Emax) Deflection at max. load, (Snom) approx. (±20%) Weight (G), approx.	kg/lb mm kg	100; 200; 300 0.45 1	500;1,000/ 1,000;2,000; 2,500 0.45 1	2,000/ 4,000; SE-5,000 0.6 1	3,000;5,000/ 5,000; 10,000 0.8 1.8	10,000/ 15,000; 20,000 1.1 4.1	20,000 1.4 5.5
Minimumload cell verification interval(Vmin) Sensitivity (Cn) Zero balance Temperature effect on sensitivity (TKc) * Temperature effect on zero balance (TKo) Non-linearity (dlin) * Repeatability (drep) * Hysteresis error (dhy) * Creep (dDR)in 30 min. Input resistance (RLC) [Red(+)-black(-)] Output resistance (RO) [Green(+)-white(-)] Reference excitation voltage (Uref) Maximal excitation voltage nsulation resistance (Ris) Nominal temperature range Service temperature range Storage temperature range	% of Cn mV/V mV/V % of Cn/K % of Cn/K % % % % O O V(DC/AC) V(DC/AC) GO OC [ o F] OC [ o F] OC[ o F]	0.03; 0.02 3±0.25% ±0.06 < ±0.0012 <±0.0040 <±0.017 <±0.017 <±0.017 < ±0.023 400 ± 25 for kg; 350 ± 7 for lb 352±3 0.5.12 18 >2[50 VDC ] -10.+40[15.+105] -30.+70[-20.+160] -50.+85[-60.+185]
Safe load limit (EL) Breaking load (Ed)	% of Cn % of Cn	150 300
Protection class (IP) acc. to IEC529		IP67
Material		Alloy Steel / Stainless Steel (available)
Optionally		Explosion proof version (Ex ib II CT4)

* The data for deviation of linearity, repeatability, hysteresis error and temperature effect on sensitivity are typical values. The sum of these data meets the requirements according to OIML R60.
