   Valve >> Solenoid valve >> VX Series

Kinetic Automatic Machinery Co.,Ltd., China Ningbo Kinetic Production Trading Co.,Ltd. is specialized in manufacturing ckd solenoid valve, ckd solenoid valves, pneumatic and hydraulic components, pneumatic and hydraulic complete kits series, aluminum parts and bending plates, plastic parts and etc. KINETIC integrates designing, manufaturing and sales sevice together. In the passed 10 years, KINETIC developed to a moden enterprise, enjoying more than 25000 square meters workshop and our products, ckd solenoid valve, ckd solenoid valves are well sold in Europe, South American, North American, the middle East and the Southeast Asia, the a wide market network of more zhan 55 countries with Ningbo FengLing and Baode Automation Industrial Co., Ltd. as our strong base.


ckd solenoid valve

Ordering Code

VX2120

08

AC220V

Specification Code Joint Pipe Bore
06: 1/8"
08: 1/4"
10: 3/8"
15: 1/2"
Standard Voltage
DC12V DC24V
AC24V 50/60Hz
AC110V 50/60Hz
AC220V 50/60Hz
AC380V 50/60Hz
     Specification
Model VX2120-06 VX2120-08 VX2120-10 VX2120-15
Working Medium Air, Water, Steam
Motion Pattern Direct Drive Type
Type Normal Close Type
Aperture of Flow Rate 3 13
Joint Pipe Bore G1/8"  G1/4"  G3/8"  G1/2"
Working-pressure 0~1.0MPa
Operation Temperature Range -5~+150oC -5~+80oC
Material of Oil Seal VITON NBR

  Click:23  Update:2006-3-7 <Print> <Back>
